| Motor: | 10 HP |
| Voltage: | 220v single phase/any voltage 3 phase |
| Cycle: | 50 or 60 |
| Bending Table Height: | 36″ |
| Bender Speed: | 10 RPMs |
| Dimensions: | 50″ (L) x 38″ (W) x 40″ (H) |
| Weight: | 2500 lbs. |
| Hydraulic oil capacity: | 32 gallons |
| Foot Control: | Standard |
| OPTIONS: | Benders Offset bends, High Speed 20 HP available |
| 1Bar No. | Bar Size (DIA) | Max. # of Bars Grade 40 and 60 |
|---|---|---|
2 | 1.4″-6.35mm | 14 |
3 | 3/8″-9.53mm | 10 |
4 | 1/2″-12.7mm | 7 |
5 | 5/8″-15.9mm | 5 |
6 | 3/4″-19.1mm | 4 |
7 | 7/8″-22.2mm | 2 |
8 | 1″-25.4mm | 2 |
9 | 1 1/8″-28.7mm | 2 |
10 | 1 1/4″-32.3mm | 1 |
11 | 1 3/8″-36.5mm | 1 |
Bending Capacity
| 1Bar No. | Bar Size (DIA) | Max. # of Bars Grade 40 and 60 |
|---|---|---|
2 | 1.4″-6.35mm | 16 |
3 | 3/8″-9.53mm | 12 |
4 | 1/2″-12.7mm | 8 |
5 | 5/8″-15.9mm | 6 |
6 | 3/4″-19.1mm | 6 |
7 | 7/8″-22.2mm | 2 |
8 | 1″-25.4mm | 2 |
9 | 1 1/8″-28.7mm | 2 |
10 | 1 1/4″-32.3mm | 1 |
11 | 1 3/8″-36.5mm | 1 |
[/fancy-ul]
| Weight | 2500 lbs |
|---|---|
| Dimensions | 50 × 38 × 40 in |
| Motor Type | Electric |
| Portability | Stationary |
| Rebar Features | Multi-Directional, Rebar Bender |
