SHEARING CHART
SHEARING CHART| REBAR # | Bar Size (DIA) | Max. # of Bars Grade 40 & 60 | |
|---|---|---|---|
| 2 | 1.4″-6.35mm | 18 | |
| 3 | 3/8″-9.53mm | 16 | |
| 4 | 1/2″-12.7mm | 14 | |
| 5 | 5/8″-15.9mm | 7 | |
| 6 | 3/4″-19.1mm | 4 | |
| 7 | 7/8″-22.2mm | 3 | |
| 8 | 1″-25.4mm | 2 | |
| 9 | 1 1/8″-28.7mm | 1 | |
| 10 | 1 1/4″-32.3mm | 1 | |
| 11 | 1 3/8″-36.5mm | 1 |
Now Offering Shear Lines, Power Dumps & Powered Feeders!
We are first because we last! High Quality manufactured rebar machines made in the USA!
Our service team is here to help when you have an issue. Worldwide support available.
We stand by our work and provide all our new machines with a full 1-year warranty.
Increase your productivity with optional accessories and attachments.
| Specification | |
|---|---|
| Motor: | 10HP |
| Voltage: | 220v single phase/any voltage 3 phase |
| Cycle: | 50 or 60 |
| Cut Height: | 36″ |
| Cycle time: | 3 seconds |
| Dimensions: | 65″ (L) x 36″ (W) x 40″ (H) |
| Weight: | 1650 lbs. |
| Hydraulic oil capacity: | 32 gallons |
| Foot Control: | Optional |
Need to speed your cutting up, and be more organized?...
This site uses Akismet to reduce spam. Learn how your comment data is processed.
No account yet?
Create an Account
Rick Meek –
Coldstream Concrete LTD.
We have an RCE11 , It has run 12-16 hour shifts for 14 years.
This is a fast, powerful and reliable machine. I highly recommend this machine .
Rating: 5 / 5
Terry Ladner design precast &pipe –
Awesome cutter saves hours quick easy to use
Rating: 5 / 5
Woody –
Great product, I highly recommend.
Rating: 5 / 5
Mark Smith –
This 11 bar machine has been flawless, we used a cut-off saw before this, what a time saver! Great Machine
Rating: 5 / 5
