| Motor: | 5 H.P. High Speed Model |
| Voltage: | 220v single phase/any voltage 3 phase |
| Cycle: | 50 or 60 cycle |
| Cut Height: | 36″ / Can be feed left to right or right to left |
| Cycle time: | 6 seconds / High Speed Model: 3 seconds |
| Dimensions: | 48″ Long x 24″ wide x 48″ tall |
| Weight: | High Speed Model 700 Lbs. |
| Hydraulic oil capacity: | 18 gal. High Speed Model |
| Foot Control: | Optional |
| Options: | Cutters Benders |
| 1Bar No. | Bar Size (DIA) | Max. # of Bars Grade 40 and 60 |
|---|---|---|
2 | 1.4″-6.35mm | 14 |
3 | 3/8″-9.53mm | 10 |
4 | 1/2″-12.7mm | 6 |
5 | 5/8″-15.9mm | 3 |
6 | 3/4″-19.1mm | 2 |
7 | 7/8″-22.2mm | 1 |
8 | 1″-25.4mm | 1 |
Shearing Capacity
| 1Bar No. | Bar Size (DIA) | Max. # of Bars Grade 40 and 60 |
|---|---|---|
2 | 1.4″-6.35mm | 14 |
3 | 3/8″-9.53mm | 10 |
4 | 1/2″-12.7mm | 6 |
5 | 5/8″-15.9mm | 3 |
6 | 3/4″-19.1mm | 2 |
7 | 7/8″-22.2mm | 1 |
8 | 1″-25.4mm | 1 |
[/fancy-ul]
| Weight | 700 lbs |
|---|---|
| Dimensions | 48 × 24 × 48 in |
| Motor Type | Electric |
| Portability | Stationary |
| Rebar Features | Cutter, High Speed |
CJ Scott –
We are in the precast concrete industry and use two of the machines in out facility. Fast and reliable.
Kevin LeClair –
we have this in our Precast plant, we cut hundreds of pcs. of bar per day for the last 15 years with out any major problem’s just preventative maintance.
Paul –
Awesome cutter, well built, takes a beating and keeps on cutting!!
